DJI Zenmuse P1

Effizienz durch flexible Vollformat-Photogrammetrie
  • GTIN: 6941565910868
  • SKU: 5507

Price on request

Wir vermitteln Sie an den passenden Fachhandelspartner aus unserem Händlernetzwerk.

Zenmuse P1 - Efficiency through Flexible Full-frame Photogrammetry

The New Benchmark for Aerial Surveying
The Zenmuse P1 integrates a full-frame sensor with interchangeable fixed-focus lenses on a 3-axis stabilized gimbal. Designed for photogrammetry flight missions, it takes efficiency and accuracy to a whole new level.



  • Accuracy without GCPs 3 cm horizontally / 5 cm vertically
  • High Efficiency 3 km2 covered in a single flight
  • 45 MP Full-frame Sensor
  • 3-axis Stabilized Gimbal Smart Oblique Capture
  • Global Mechanical Shutter Shutter Speed 1/2000 Seconds
  • TimeSync 2.0 - synchronization at the microsecond level

Your Go-to Tool for Aerial Photogrammetry


Extraordinary Efficiency
The P1 includes a full-frame, low-noise high-sensitivity sensor that can take a photo every 0.7 s during the flight, and covering 3 km2 in a single flight.















Remarkable Accuracy
Equipped with a global mechanical shutter and the all-new TimeSync 2.0 system, which synchronizes time across modules at the microsecond level, the Zenmuse P1 lets users capture centimeter-accurate data combined with the real-time position and orientation compensation technology.















Robust Versatility
Create 2D, 3D, and detailed models thanks to the integrated 3-axis gimbal that can be outfitted with 24/35/50mm lenses and the Smart Oblique Capture feature.















Efficiency to Cover It All - Full-frame Camera

  • 45MP Full-frame Sensor
  • 4.4μm Pixel Size
  • Low-noise, high sensitivity imaging extends daily operational time
  • Take a photo every 0.7 s during the flight
  • TimeSync 2.0 aligns the camera, flight controller, RTK module, and gimbal at the microsecond level

Flexibility to Capture it All
Multiple Fixed-focus Lens Options

  • Global Mechanical Shutter, Shutter Speed 1/2000 Seconds
  • Sends the median exposure pulse in microseconds
  • Supports 24/35/50mm lenses with DJI DL mounts

Work Smart, Work Fast


Smart Oblique Capture
Cover 7.5 km2 in a single workday with the P1. Elevate the efficiency of your oblique photography mission using Smart Oblique Capture, where the gimbal automatically rotates to take photos at the different angles needed. Only photos essential to the reconstruction will be taken at the edge of the flight area, increasing the efficiency of post processing by 20% to 50%.

Smart Data Management
Your mission data management - streamlined.

  • Mission result files are automatically associated with the Mission Name and Mission Time.
  • A centralized storage location for photos, GNSS data, and Tim.eStamps.MRK files.
  • The image metadata contains the camera’s intrinsic and extrinsic parameters and the status of RTK.















Fieldwork Report
Verify data quality immediately post-flight by checking the position data and number of the images acquired, as well as RTK status and positioning accuracy.















A Mission Mode for Any Scenario

  • 2D Orthomosaic Mission
  • 3D Oblique Mission
  • Detailed Modeling Mission
  • Real-time Mapping Mission

Application Scenarios

Topographic Mapping
Capture data that meet the 1:500 scale accuracy requirements without GCPs.









Cadastral Surveying
Quickly generate centimeter-level accurate 3D reality models.









AEC and Surveying
Manage the full project lifecycle with 2D and 3D drone data.









Natural Resource Management
Measure, classify, or determine the ownership of water bodies and forests.









Geological Investigation
Safely gather millimeter-level accurate aerial data of geological hazard sites.









Disaster Site Modeling
Gain real-time overviews of vast disaster-struck areas to help teams make critical decisions.









In the Box:

1x Zenmuse P1 incl. 35mm Objektiv
1x Care Enterprise Basic service for Zenmuse P1 (12 months)

Important:
The Zenmuse P1 comes with a 35mm lens.

3-month trial license of the DJI Terra software included!
Note: This offer is valid for the first aircraft in your DJI Account.


ZENMUSE P1

General

Product Name
ZENMUSE P1

Dimensions
198×166×129 mm

Weight
Approx. 800 g

Power
20W

IP Rating
IP4X

Supported Aircraft
Matrice 300 RTK

Operating Temperature Range
-20° to 50° C (-4° to 122° F)

Storage Temperature Range
-20° to 60° C (-4° to 140° F)

Absolute Accuracy
Horizontal: 3 cm, Vertical: 5 cm *
* Using Mapping Mission at a GSD of 3 cm and flight speed of 15 m/s, with an 75% front overlap rate and a 55% side overlap rate.

Camera

Sensor
Sensor size (Still): 35.9×24 mm (Full frame)
Sensor size (Max video recording area): 34×19 mm
Effective Pixels: 45MP
Pixel size: 4.4 μm

Supported Lenses
DJI DL 24mm F2.8 LS ASPH (with lens hood and balancing ring/filter), FOV 84°
DJI DL 35mm F2.8 LS ASPH (with lens hood and balancing ring/filter), FOV 63.5°
DJI DL 50mm F2.8 LS ASPH (with lens hood and balancing ring/filter), FOV 46.8°

Supported SD Cards
SD: UHS-I rating or above; Max capacity: 512 GB

Storage Files
Photo / GNSS Raw Observation Data/ Image Log File

Photo Size
3:2 (8192×5460)

Operation Modes
Photo, Video, Playback

Minimum photo interval
0.7 s

Shutter Speed
Mechanical Shutter Speed: 1/2000*-1 s
Electronic Shutter Speed: 1/8000-1 s
*Aperature value no larger than f/5.6

Aperture Range
f/2.8-f/16

ISO Range
Photo: 100-25600
Video: 100-25600

Video

Video Format
MP4,MOV

Video Resolution
16:9 (1920×1080)
16:9 (3840×2160)*
*Only 35mm lens supported

Frame Rate
60fps

Gimbal

Stabilized System
3-axis (tilt, roll, pan)

Angular Vibration Range
±0.01°

Mount
Detachable DJI SKYPORT

Mechanical Range
Tilt: -130° to +40°;
Roll: -55° to +55°;
Pan: ±320°

DJI Zenmuse P1 delivery includes ex works the DJI Care Enterprise Basic service, which is valid for 12 months. Against payment of a fee DJI Care Enterprise Basic allows for up to 2 replacement devices during that period in case of defective aircraft.

1st exchange fee: 430€
2nd exchange fee: 480€

After 12 months, the service can be extended twice for another 12 months. The service can be extended to a maximum of 36 months.

(Item no. 7365)

During the activation process of the aircraft, DJI Care Enterprise Basic will either be activated automatically in the background or ask the user to confirm its activation in a pop-up window.

Verification of the activation as well as a check of the current status of Care may be done via the following link:

Checking of Care Activation

Manufacturer

Name: SZ DJI Technology Co.,Ltd

Street: Lobby of T2, DJI Sky City, Xianyuan Road, Xili Community, Xili Street, Nanshan District No. 53

Location: 518057 Shenzhen

Country: China

E-Mail: support@dji.com

Homepage: https://www.dji.com

Sicherheitshinweise für die Nutzung von Drohnen

  1. Einhaltung der Gesetze

    Bitte halten Sie sich an die lokalen und nationalen Gesetze für den Betrieb von Drohnen. Informieren Sie sich vor dem Flug über die geltenden Vorschriften.

  2. Registrierung

    Stellen Sie sicher, dass Ihre Drohne registriert ist, falls dies gesetzlich vorgeschrieben ist. Dies ist oft notwendig, bevor Sie Ihre Drohne fliegen dürfen.

  3. Flugverbotszonen

    Fliegen Sie nicht in Flugverbotszonen wie Flughäfen, Naturschutzgebieten oder dicht besiedelten Gebieten. Informieren Sie sich über die erlaubten Flugzonen in Ihrer Region.

  4. Sichtweite

    Fliegen Sie Ihre Drohne immer in Sichtweite. Vermeiden Sie es, die Drohne aus den Augen zu verlieren, um die Kontrolle zu behalten.

  5. Höhenbegrenzung

    Halten Sie sich an die maximal erlaubte Flughöhe für Drohnen in Ihrer Region. Dies hilft, Kollisionen mit anderen Flugobjekten zu vermeiden.

  6. Sicherheitsabstand

    Halten Sie einen sicheren Abstand zu Menschen, Tieren und Gebäuden ein. Dies schützt sowohl die Drohne als auch die Umgebung.

  7. Wetterbedingungen

    Fliegen Sie Ihre Drohne nur bei guten Wetterbedingungen. Vermeiden Sie starke Winde, Regen oder andere extreme Wetterlagen.

  8. Privatsphäre

    Respektieren Sie die Privatsphäre anderer. Vermeiden Sie es, ohne Erlaubnis Bilder oder Videos von Personen aufzunehmen.

  9. Wartung und Inspektion

    Überprüfen Sie Ihre Drohne regelmäßig auf Schäden und führen Sie notwendige Wartungsarbeiten durch. Dies verhindert technische Probleme während des Fluges.

  10. Notfallmaßnahmen

    Seien Sie auf Notfälle vorbereitet. Wissen Sie, wie Sie Ihre Drohne sicher landen können, falls ein technisches Problem auftritt.

  11. Versicherung

    Wir empfehlen den Abschluss einer Haftpflichtversicherung für den Betrieb Ihrer Drohne. Dies schützt Sie im Falle eines Unfalls oder Schadens.

Sicherheitshinweise für die Lagerung und Verwendung von Lithium-Akkus

  1. Lagerungstemperatur

    Bewahren Sie Lithium-Akkus an einem kühlen, trockenen Ort auf. Die ideale Lagertemperatur liegt zwischen 15°C und 25°C.

  2. Feuchtigkeit vermeiden

    Halten Sie die Akkus fern von Feuchtigkeit und Wasser. Lagern Sie sie in einem trockenen Raum, um Korrosion und Schäden zu vermeiden.

  3. Direkte Sonneneinstrahlung vermeiden

    Setzen Sie die Akkus nicht direkter Sonneneinstrahlung aus. Hohe Temperaturen können die Akkus beschädigen und die Lebensdauer verkürzen.

  4. Feuergefahr

    Lagern Sie Lithium-Akkus niemals in der Nähe von brennbaren Materialien. Im Falle eines Defekts können sie Feuer fangen.

  5. Beschädigte Akkus entsorgen

    Verwenden Sie keine beschädigten oder aufgeblähten Akkus. Entsorgen Sie diese sicher gemäß den lokalen Vorschriften.

  6. Ladegeräte verwenden

    Verwenden Sie nur die vom Hersteller empfohlenen Ladegeräte. Falsche Ladegeräte können zu Überhitzung und Schäden führen.

  7. Überladung vermeiden

    Laden Sie die Akkus nicht über die empfohlene Kapazität hinaus. Überladung kann zu Überhitzung und im schlimmsten Fall zu einem Brand führen.

  8. Kurzschlüsse vermeiden

    Vermeiden Sie Kurzschlüsse, indem Sie die Kontakte der Akkus nicht mit Metallgegenständen in Berührung bringen.

  9. Regelmäßige Überprüfung

    Überprüfen Sie die Akkus regelmäßig auf Schäden oder Abnutzung. Ersetzen Sie alte oder beschädigte Akkus rechtzeitig.

  10. Notfallmaßnahmen

    Halten Sie geeignete Löschmittel bereit, um im Falle eines Akku-Brandes schnell reagieren zu können. Ein Feuerlöscher für Lithium-Brände ist empfehlenswert.

  11. Entsorgung

    Entsorgen Sie Lithium-Akkus nicht im Hausmüll. Bringen Sie sie zu einer Sammelstelle für Batterien oder Elektronikschrott.
